<p>Occupied\/Unoccupied,Report Mode:Report When State Changes,Unoccupied To Occupied,Report Within 0.5s,Occupied To Unoccupied,Output Unoccupied State In 40s;Occupied Stationary\/Occupied Active,Report Mode:Report When State Changes,Switch Between Stationary And Active,Report Within 0.5s;Human Body Distance Active,Report Mode:Output Data Once In 2s,Distance Unit:Cm,Distance Range:0-65535cm;Body Movement Amplitude Parameter 0-100,Report Mode:Output Data Once In 1 Sec,Distance Range:0-65535cm</p> <p>Body Movement Amplitude Parameter 0-100,Report Mode:Output Data Once In 1 Sec;Distance Unit:Cm,Distance Range:0-65535cm;Body Movement Amplitude Parameter 0-100,Report Mode:Output Data Once Every 1 Second.Human Body Orientation Active Reporting,Reporting Mode:2 Seconds To Output Data,6byte,Each 2byte Represents A Direction (X,Y,Z),Unit:Cm,Orientation Information Has Positive And Negative,Each Direction Of The 2byte16 Hexadecimal Data Is Converted To Binary Data 16-Bit Data</p> <p>The First 0 Means Negative,The First 1 Means Positive,The Remaining 15Bits In Accordance With The High Position In The First Converted To Decimal,That Is,To Get The Specific Coordinates.The First Bit Is 0 For Negative,The First Bit Is 1 For Positive,And The Remaining 15 Bits Are Converted To Decimal Before The High Bit To Get The Specific Coordinate Value;Heartbeat Value,Reporting Mode:3s Output Data Once,Value Range:50-120</p> <p>Heart Rate Waveform,Reporting Mode:1s Output Data Once,Reporting Mode:1s Output Data Once,5 Bytes The 5 Values In 1s In Real Time,Which Is The Real Value +128 (To Let The Display Of The Curve As A Whole Is In The Middle Of The Coordinate Axis,For A Better Display Experience);Respiration Value. Reporting :Output Data Once In 3s.Respiratory Information, Reporting Mode: Report When The State Changes</p> <p>Respiratory Waveform,Reporting Mode:Output Data Once In 1s; Bed In\/Bed Out, Reporting Mode:Report When The State Changes;Sleep State(Awake\/Light Sleep\/Deep Sleep),Reporting Mode:Output Data Once In 10min Under The Bed In State.Awake Time\/Light \/Deep ,Reporting :Under The Bed State,Output The Latest Data Of The Corresponding Time Following The Sleep State Of 10min</p> <p>Sleep Quality Score,Report The Score Of The Sleep Segment At Of The Sleep Process,With The Score Ranging From 0 To 100;Report The Comprehensive Sleep State,Reporting :Once Every 10 Minutes;Report The Sleep Quality Analysis,Reporting :Report The Whole Night'S Sleep Quality At Of The Sleep Process When The Sleep Process Is Judged To Be Over.Sleep Quality Analysis Is Reported In The Following Way:When The Sleep Process Is Judged To Be Over,The Sleep Statistics Of The Whole Night Are Reported</p> <p>Sleep Abnormality Report,Abnormal Struggle Report,Unoccupied Time Report,Sleep Quality Rating Report,Report Mode:Report When The State Changes</p> <p>Type:Module</p> <p>Notes:</p> <p>1. GP1-GP4 Are Parameter Selection Control Terminals,Which Can Be Redefined According To User's Requirement</p> <p>2. The Output Signals Of This Interface Are All 3.3VTTL Level</p> <p>Tools Preparation</p> <p>1. Ttl Serial Tool, Cable,Pc,Serial Assistant Terminal</p> <p>2. Radar-EVB Demo Board(Default Graffiti Platform,Free To Adapt Their Own Communication Modules)</p> <p>3. Radar User Manual(Protocol)</p> <p>Different Batches May Have Differences In Product Appearance,Color,And Printed Characters,Which Will Not Affect The Use</p> <p>Colour:Green</p> <p>Material:PCB</p> <p>Size:3.5x3cm</p> <p>Package Contents:</p> <p>1 * Module</p> <p>Only the above package content, other products are not included.</p> <p>Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +\/- 1-3cm.</p>
